Underground Hydrant

DN 80 … 100
PN 10 & PN 16
Field of application: Water supply and distribution from main pipe line in case of fire fighting and etc. in cities, hospitals, educations departments and etc. up to 70°C.
It is mainly used for installation in low depths or brick walled bricks.

Features:
- Design: according to BS 750
- Flanges: according to DIN 2501
- Hydrostatic test pressure: according to DIN EN 12266-1
- Corrosion protection: Completely coated with red color (RAL 3020) electro -static polyester powder coating according to DIN 30677-T2
- 11/2 or 65 mm threaded outlet coupling
- Automatic drain system of this valve ensures total emptying of the hydrant after use.

Materials:
- Nozzle section, Barrels, Main valve and Foot bend: Ductile Cast Iron 1693 (GGG40)
- Gate: Ductile Cast Iron DIN 1693 (GGG40) Core with vulcanized rubber coating of EPDM
- Stem: Stainless steel (X20Cr13), left-hand rolled thread according to DIN 103
- Elastometric Parts: EPDM
